Flammability Tester
Flammability Tester

Flammability Tester

55000 INR/Unit

Product Details:

  • Material Stainless Steel
  • Power Source Electric
  • Weight 25 Kg Kilograms (kg)
  • Click to View more
X

Flammability Tester Price And Quantity

  • 1 Unit
  • 55000 INR/Unit

Flammability Tester Product Specifications

  • Electric
  • Stainless Steel
  • 25 Kg Kilograms (kg)

Flammability Tester Trade Information

  • 20 Unit Per Week
  • 4 Days
  • Wooden Packing
  • All India

Product Description

Flammability Tester

TEXCARE INSTRUMENTS Provides Top Quality Of Flammability Tester For Fabric, Clothing, Tents, Etc.

Texcare Instruments makes over to selecting the high-quality constituents from leading manufacturers and collaborates with relative industrial leaders to develop Flammability Tester that efficiently measures ignition temperature of fabrics with the promise of unparallelled performance and effective functioning. The efficiency value of high-technology Flammability Tester further extends due to embodying the advanced temperature sensor for identifying the ignition temperature of the sample through measuring surrounding atmosphere as well as temperature of the sample, thus defining the ignition properties of materials. With persistent endeavour, expertise, experience and dedication, we are able to manufacture, supply and export an ingeniously engineered models of Flammability Tester that get accreditation because of its efficiency in testing the flammability attributes of combustible material such as plastic films, fabrics and the like, more specifically automatically testing the ease of ignition and rate of burning. Being India's prominent Manufacturer and Exporter of flammability tester, we make use of innovation to empower our business and benefit our customers, and make a real difference to our functional industry.


The flammability of fabrics can be identified by igniting one end of fabric, which is only possible with the help of a suitable flammability tester that has intelligent sensor to find out specified flame intensity and determination of burning time. Along with that, the extent of transfusion of flame and the time taken by the flame to propagate between two marked levels can also be determined. Similarly, in a vertical type strip flammability tester, the procedure of determination is different, in which a specimen is cut from the fabric that is inserted into the frame and held vertically inside an enclosure and the flame from Bunsen burner is applied at its lowermost edge. Then the time taken by the flame to propagate between two specified points is determined. This entire process shows the numerical rating of flame resistance. It is the most appropriate method to determine the combustible property of all fabrics which are in form of sheets or that is converted into sheets by cutting method.

Additional Information:

The flammability of fabrics can be identified by igniting one end of fabric, which is only possible with the help of a suitable flammability tester that have specified flame intensity. Along with that, the extend of propagation of flame and the time taken by the flame to propagate between two marked levels can also be determined. Similarly, in a vertical type strip flammability tester the procedure of determination is different, in which a test specimen is cut from the fabric under test is suspended vertically inside an enclosure and the flame from Bunsen burner is applied at its lowermost edge. Then the time taken by the flame to propagate between two specified points is determined. This entire process shows the numerical rating of flame resistance. It is the most appropriate method to determine the property of all fabrics which are in form of sheets or that is converted into sheets by cutting method.

Key Features:

  • Equipped with PLC to manage testing unit.
  • Test burner according to ISO, will burn at 45 deg or 90 deg.
  • Auto begin and stop perform, temporal order perform.
  • Exhaust vents at all-time low and high of take a look at chamber guarantee sensible ventilation and steady flame.
  • Ignition time and burning time punctually displayed on crystal rectifier panel.
  • Stop lighting mechanically once igniting 15s.
  • Specially offer bimetallic comb for pile materials.

Technical Specifications of Flammability Tester :

  • Digital Timer
  • Flame Length 16 mm
  • Flame Source - L.P.Gas
  • Flexible Tubing 1.5 meter
  • Burning Area 105 mm x 40 mm
  • Size of Specimen Holder 175 mm x 80 mm
  • Multipurpose gauge to measure flame length.
  • Specimen cutting template size 500mm x 150mm
  • Specimen Holder receiver tray position 45 Angle
  • Stainless Steel Body with fine quality acrylic door.

Related Standards

  • ASTM D 1230
  • CRF 16-1610
  • FTMS 191-5908
